Escalator
Outstanding Performance, Enhancing Quality
By integrating the quality assurance system, advanced manufacturing processes, and meticulous workmanship, VOSAM has created high-quality escalator products. Combining advanced technology, diverse functions, and elegant designs, Walson has driven the innovative development of escalator manufacturing across the country. VOSAM escalators not only create traffic flow in commercial buildings, hotels, and airports but also bring unique lifestyle pleasures to consumers.

Descriptions

Parametric

Low frequency conversion
The variable frequency escalator operates smoothly. If the escalator is unloaded within the set time, the escalator speed will be reduced, and the no-load energy saving effect will be greater than 60%.
Inverter starts automatically
If the escalator has no load within the set time, the elevator will run at low speed or stop running within the specified time.

Intelligent transmission system

The control system automatically determines the load condition of the escalator through sensors and realizes automatic multi-level speed switching in real time, providing passengers with a comfortable taking experience while greatly reducing energy consumption and achieving no-load.


serial number safety equipment Function Description
1 Electrostatic protection Eliminate static electricity generated during operation on steps (pedals), handrails and other parts.
2 emergency stop

When emergency stop is required, press the emergency stop switch for protection.

3 apron protection It protects when foreign objects are caught between the steps (pedals) and the apron.
4 Handrail entrance security protection It protects the entrance of the handrail when foreign objects are caught.
5 Drive chain break protection Protects when the drive chain breaks or is too long.
6 Over speed protection It takes effect when the escalator/moving walkway speed exceeds 20% of the rated speed.
7 Under speed protection It takes effect when the escalator/moving walkway speed is lower than 80% of the rated speed.
8 Non-operation reversal protection It protects when the running direction of steps (pedals) and handrails is opposite to the specified direction.
9 Interruption and wrong phase protection It protects when the power supply phase is missing or out of phase.
10 Short circuit protection It protects when the power circuit is short-circuited.
11 Overload protection It protects the motor when it is continuously overloaded.
12 Step (pedal) subsidence protection It protects when the steps (pedals) are damaged and sink.
13 Step (pedal) chain protection It protects when the step (pedal) chain breaks or is too long.
14 Comb tooth safety protection Protects when foreign matter gets caught in the comb teeth.
15 Anti-static handrail Eliminate static electricity generated by handrails during operation.
16 Access socket Provide safe voltage for inspection or maintenance.
17 Machine room guard plate Isolate the machine room from moving parts such as steps or pedals to provide a safe space for repair or maintenance.
18 Emergency stop protection During maintenance and repair, when danger occurs or there is a possibility of danger, press the emergency stop switch to protect people and equipment.
19 Auxiliary braking The auxiliary brake stops the escalator/walk when the drive chain breaks and the steps, pedals and handrails run in the opposite direction to the designated direction.
20 handrail protection It protects the handrail when its speed changes or breaks.
21 apron brush Prevent passengers or foreign objects from being caught between the apron board and steps/pedals.
Escalator Vosam integrates a quality assurance system, advanced manufacturing processes, and a meticulous work ethic to create high-quality automatic escalator products. By combining cutting-edge technology, diverse functionality, and elegant designs, VOSAM has driven innovative advancements in the national automatic escalator manufacturing industry. These escalators not only facilitate traffic flow in commercial buildings, hotels, and airports but also bring unique lifestyle enjoyment to consumers.
